Hebei Shengtong Metal Products Sales Co., Ltd. is one of the leading manufacturers and suppliers of high quality gabion(woven gabion) in China. If you're going to buy cheap high quality gabion(woven gabion) made in China, welcome to get free sample from our factory. Customized orders are welcome.
Woven Gabion： made of high-quality galvanized steel wire or PVC coated wire. It is widely used in various civil engineering projects for slope protection, river bank protection, retaining walls, and landscaping.
Woven Gabion is not only durable and long-lasting, but also flexible and easy to install. It provides an effective solution for stabilizing soil and preventing erosion in challenging terrains. With its excellent permeability, the stone cage net allows for proper drainage and promotes vegetation growth, creating a harmonious blend of structure and nature.
In addition to its practicality, the stone cage net also adds an aesthetic appeal to the surroundings. By filling the cages with various sizes and colors of stones, it can enhance the visual appeal of the project and blend seamlessly with the natural environment.
Overall, the stone cage net is a versatile and reliable solution for a variety of engineering and landscaping applications. Its combination of strength, flexibility, and aesthetic appeal makes it a popular choice for projects around the world.
Specifications
|
Aperture |
Wire Diameter |
Edge wire |
Gabion Sizes (m) |
Material (zinc coating) |
|
60x80mm |
2.2mm / 2.7mm |
2.4mm / 3.4mm |
6x2x0.3m / 2x1x0.5m |
1. Galvanized steel wire 2. High zinc steel wire 3. PVC coating steelwire |
|
80x100mm |
2.7mm / 3.0mm / 3.2mm |
2.4mm / 3.4mm |
2x1x1 / 3x1x1m / 4x1x1m |
|
|
100x120mm |
3.0mm / 3.05mm / 3.2mm |
3.4mm |
3x1x1 / 4x1x1m / 5x1x1m |
|
|
Material |
High-strength steel wire, galvanized or PVC coated, corrosion-resistant. |
|
Wire Gauge |
vailable in a variety of wire gauges, typically ranging from 2.0mm to 4.0mm, depending on the strength required for the application. |
|
Mesh Size |
Standard mesh sizes range from 50mmx50mm to 100mmx100mm; custom sizes available upon request. |
|
Basket Size |
Can be customized to meet specific project requiremens. Standard sizes typically range from 1mx1mx1m to larger sizes (3mx1mx1m, 6mx1mx1m, etc.) |
|
Fill Material |
Typically filled with natural stone, gravel or other locally available materials. Infill options may vary depending on aesthetic preferences and structural requirements. |
Applications
Retaining Walls: Woven gabions are commonly used to create strong, durable retaining walls for commercial and residential projects. They provide an effective solution for stabilizing slopes, preventing soil erosion, and supporting embankments.
Erosion Control: Ideal for protecting riverbanks, shorelines, and other vulnerable areas from erosion caused by wind, water, or traffic. Woven gabions help protect soil and reduce long-term erosion.
Landscaping and Garden Design: Woven gabions can be used in landscaping to create attractive features such as garden walls, seating areas, and decorative structures. The natural stone fill has a rustic, natural look that blends in beautifully with outdoor settings.
Noise Barriers: These gabions can also be used as effective noise barriers along highways, railways or other noisy areas. Their strong structure and soundproofing properties help reduce noise pollution and improve comfort in surrounding areas.
River and Coastal Protection: Woven gabions are an excellent choice for protection against flooding and wave erosion, and are ideal for riverbank and coastal defense applications.
Why Choose Our Woven Gabions?
Durable and Long-Lasting: Our gabions are made from high-quality, corrosion-resistant wire, ensuring they can withstand the elements and maintain their integrity over time.
Strong and Flexible: The woven design combines flexibility and strength, allowing the gabions to adapt to different landscapes and pressures while providing reliable structural support.
Eco-Friendly Solutions: By using natural stone or locally sourced materials as infill, our woven gabions contribute to sustainable building practices and minimize environmental impact.
Versatile: From erosion control and slope stabilization to decorative garden walls and noise barriers, our gabions are versatile enough to meet the needs of a wide range of projects.
Cost-Effective: Woven gabions offer an affordable solution for large projects. Their durability reduces the need for maintenance or replacement, making them a smart long-term investment.
